Tri-Temp Tier IV AH1.5 | Flameless Heater

Tri-Temp’s flameless mobile heaters have been designed for reliability, safety, and ease of operation.  From its industrial Tier 4 final engine to the Industry Standard Dynamic Heat Generator (DHG) the unit is ready for work. Its flameless design offers the ability to operate in environments from construction sites, to oil well pads, to supplemental plant operations and in the construction field.

Tri-Temp offers a “One Touch Screen”.  Upon entering a pass code, the “One Touch Screen” is energized and with one touch the unit will start.  The controller will review operational parameters if met the self-regulation of the unit during warm up cycle and transition to operational heat mode.  This provides control and allows for tempered air flow during operation.  To shut down the unit, the same “One Touch Screen” is used.  This allows the unit to decrease in operational speed, cooling down and providing for a proper shut down sequence and diagnostics overview. The “One Touch” provides a safe operation for the unit while letting the operator move onto the next task.

Fuel economy is gained with advancements of power trimming while approaching the temperature set point, the unit will derate power while maintaining air flow and thus leading to a decrease fuel consumption. Tri-Temp also offers a maintain mode, allowing the unit to shut down once operational temperature/parameter are met, if set point falls outside the parameter the unit will restart to full fill the heat generation requirements.

Security to Tri Temp means 110% containment as all fluids on board and more can be contained within the unit. Security is also achieved in the ability to lock the entire cabinet warding off potential issues.  In another light, when dusk approaches the unit is equipped with LED lights to not only luminate the interior but the exterior as well, offering a secure work environment and further compliance to operational requirements of the site or facility.

To assist the operator, external strobes offer information at a glance.  Green for all normal, flashing green/amber indicates low fuel and red indicates that service is required.  The TTE Online App provides information about operational hours, fuel usage, location (geo fencing – safety monitoring and theft prevention) of unit and operation maintenance. The app may also send the user text or email message alerts for low fuel or operational status.

Tri-Temp units offer an unmistakable difference, with a mix of quite power, proven performance and exceptional value, the only question is…. Have you experienced the Tri-Temp difference?



MODELS AH1.5
Engine Deere
Model 6068
EPA Tier Tier 4
Horsepower hp (KW) 200 (149)
VOLUME
Fuel Tank gal (L) 275 (1250)
Run Time 100% Load hrs.* 26.1
Fuel Consumption per hr.* 10.5 (39.7)
HTF Syn ATF gal(L) 40 (400)
HEATER
Heater Output BTU/hr. 1,500,000
Max Outlet Temp 185F (82C)
Heater Eff 92%
AIR DISTRIBUTION
Fan Flow Rate CFM 9500
Fan Static Pressure 7.0
Duct Qty / Diameter 2)12 or 16
Duct Length ft.(M) 25(7.62)
CHASSIS
Dimensions (L x W x H) 198” x 84” x 98”
Weight 6,750
Hitch Ball Std (Pintle Optional) 2 5/16
ELECTRICAL SYSTEM
ELECTRICAL SYSTEM 12VDC 180amp
COLD WEATHER PACKAGE
Oil Pan Heater 150watt/60
Battery Blanket 250watt/60
Battery Maintainer 2amp/12VDC
Engine Block Heater 800watt/60
LIGHTS
Cabinet Lights LED Flood 12VDC
Exterior Unit Lights LED Flood 12VDC
LED STROBE WARNING SYSTEM
Red and Green Strobe 12VDC
